COLPOSCOPE
, 2064-B/10, SHOP NO.8
View Mobile Product Description
TECHNICAL DESCRIPTIONS
Binocular Tubes: 45deg.INCLINED (OR) 90deg. Staright
Eye Pieces : 12.5x wide field
Magnifications : 3-Step (5x,10x,20x)
Objective Lens : F=300 mm
Field of View : 40mm
IPD Adjustment : 55mm to 75mm
Fine Focusing : Manual Fine Focusing By Knob
Illumination : 15V/150W twin Halogen Lamps with 100% coaxial through the lenses focused Fiber optics light guide 1.5 meter,bright light more than 80,000 Lux, maximum at standard condition
Field of Illumination : 70mm
Arm : Counter balanced pantographic arm with 320 degree
rotation.
Vertical Range of Counter Balanced Arm : 250mm to 300mm
Floor Stand : Mobile floor stand on caster wheels for easy
handling and absolute stability.
Weight : 45kg (Approx.)
Power : AC 220V, 50/60Hz.
(110V on request)
ACCESSORIES:-
1. Beam Splitter with C’ Mount2. CCD Camera for live view only, on TV Monitor.
3. LED TV Monitor
